Netgear GS305EPP-100PES

5 5 ratings
Switch -, QoS, PoE, VLAN, L3, desktop
  2,749,-
Installment calculator from  83,- monthly

Netgear GS305EPP-100PES

The GS305EPP-100PES smart switch supports selected L2 and L3 features, offering QoS, VLAN and IGMP snooping technologies, among others. It is equipped with DoS attack protection and supports management via a web-based GUI. The GS305EPP-100PES switch is the perfect upgrade from basic unmanaged switches, providing essential network features at an affordable price.

Key features of the NETGEAR GS305EPP-100PES smart switch

  • The NETGEAR GS305EPP-100PES expands your ethernet network with a total of 5 ports at 10/100/1000Mbps
  • 4 ports with Power over Ethernet (PoE+)
  • IPv6, VLAN and QoS features
  • Forwarding modes: store-and-forward
  • Bandwidth (non-blocking, full-duplex): 10Gbps
  • Priority queue: Weighted Round Robin (WRR)
  • Max. number of MAC entries: 4K
  • Multicast groups: 128
  • Number of VLANs: 64
  • Routing protocol: IGMPv2, IGMP, IGMPv3
  • LEDs: speed, link, activity, PoE

Power over Ethernet

The NETGEAR GS305EPP-100PES smart switch supports Power over Ethernet. This allows it to supply power to VoIP phones, IP cameras, access points and similar devices via an ethernet cable. The maximum power for a port is 30W and the total budget for the 4 powered ports is 120W.

Specifications

Compare
Design
Desktop
Use
Company

Functions

Ports

10/100/1000Base-T
5

Number of LAN ports

Number of LAN ports with 1 Gbit speed
5

PoE properties

PoE standard
802.3af (PoE), 802.3at (PoE+)
Performance
120 W
Maximum output power per port
30 W
Number of PoE ports
5 ×

Features

Power Supply
From the network
Maximum number of VLANs
64 ×

Speed

Switching capacity
10 Gb/s

Dimensions

Width
158 mm
Height
27 mm
Depth
101 mm

Material

Body material
Metal

Operating temperature

Minimum operating temperature
0 °C
Maximum operating temperature
40 °C

Weight

Weight
400 g
More Specifications

Fiona Spratt, NETGEAR International Limited, Floor Six, Penrose Two, Penrose Dock, Cork City, T23 YY09, [email protected]

Note:

Specifications can be changed without notice. Images are for illustrative purposes only.
